SKU:

A065007

Weight:

9,580.00 Grams

Width:

24.00 (cm)

Height:

57.00 (cm)

Depth:

28.00 (cm)

Shipping:

Calculated at Checkout

Outlet Diameter:

57.15 mm (2.25 inch)

Brand:

Cyclopac™

Country Of Origin:

United States

HTS Code:

8421310052

NMFC Code:

069100-06

Gross Height:

22.4 IN

Gross Length:

11.2 IN

Gross Volume:

1.3502 FT3

Gross Weight:

9.615 LB

Gross Width:

9.3 IN

Family:

FWA

Body Length:

343.408 mm (13.52 inch)

Rated Flow HR:

3.5 m³/min (124 cfm)

Rated Flow LR:

2.8 m³/min (99 cfm)

Rated Flow MR:

3.2 m³/min (113 cfm)

Inlet Diameter:

63.5 mm (2.50 inch)

Overall Length:

490.78 mm (19.32 inch)

Restriction HR:

254 mm H2O (10.00 inch H2O)

Restriction LR:

152 mm H2O (5.98 inch H2O)

Restriction MR:

203 mm H2O (7.99 inch H2O)

Body Diameter Maximum:

165.1 mm (6.50 inch)
