SKU:

A100019

Weight:

34,880.00 Grams

Width:

36.00 (cm)

Height:

51.00 (cm)

Depth:

76.00 (cm)

Shipping:

Calculated at Checkout

Outlet Diameter:

101.6 mm (4.00 inch)

Brand:

Cyclopac™

Country Of Origin:

United States

NMFC Code:

069100-04

Gross Height:

20 IN

Gross Length:

30 IN

Gross Volume:

4.8611 FT3

Gross Weight:

24.07 LB

Gross Width:

14 IN

Family:

FWA

Body Length:

403.5 mm (15.89 inch)

Rated Flow HR:

9.4 m³/min (332 cfm)

Rated Flow LR:

7.2 m³/min (254 cfm)

Rated Flow MR:

8.4 m³/min (297 cfm)

Inlet Diameter:

95.25 mm (3.75 inch)

Overall Length:

679.7 mm (26.76 inch)

Restriction HR:

254 mm H2O (10.00 inch H2O)

Restriction LR:

152 mm H2O (5.98 inch H2O)

Restriction MR:

203 mm H2O (7.99 inch H2O)

Body Diameter Maximum:

258.83 mm (10.19 inch)
