SKU:

A110052

Weight:

66,830.00 Grams

Width:

54.00 (cm)

Height:

66.00 (cm)

Depth:

75.00 (cm)

Shipping:

Calculated at Checkout

Outlet Diameter:

139.7 mm (5.50 inch)

Brand:

RadialSeal™

Country Of Origin:

United States

HTS Code:

8421310052

NMFC Code:

069100-09

Gross Height:

26 IN

Gross Length:

29.5 IN

Gross Volume:

9.4321 FT3

Gross Weight:

30 LB

Gross Width:

21.25 IN

Style:

Radialseal

Family:

ERA

Body Length:

517.91 mm (20.39 inch)

Rated Flow HR:

27.5 m³/min (971 cfm)

Rated Flow LR:

21.2 m³/min (749 cfm)

Rated Flow MR:

24.6 m³/min (869 cfm)

Inlet Diameter:

152.4 mm (6.00 inch)

Overall Length:

638.05 mm (25.12 inch)

Restriction HR:

254 mm H2O (10.00 inch H2O)

Restriction LR:

152 mm H2O (5.98 inch H2O)

Restriction MR:

203 mm H2O (7.99 inch H2O)

Body Diameter Maximum:

279.4 mm (11.00 inch)
