SKU:

A130115

Availability:

Call for availability

Weight:

69,770.00 Grams

Width:

54.00 (cm)

Height:

68.00 (cm)

Depth:

76.00 (cm)

Shipping:

Calculated at Checkout

Outlet Diameter:

152.4 mm (6.00 inch)

Brand:

RadialSeal™

Country Of Origin:

United States

HTS Code:

8421310052

NMFC Code:

069100-03

Gross Height:

26.65 IN

Gross Length:

29.88 IN

Gross Volume:

9.7372 FT3

Gross Weight:

34.69 LB

Gross Width:

21.13 IN

Style:

Radialseal

Family:

ERA

Body Length:

512.83 mm (20.19 inch)

Rated Flow HR:

25.2 m³/min (890 cfm)

Rated Flow LR:

21.5 m³/min (759 cfm)

Rated Flow MR:

24.9 m³/min (879 cfm)

Inlet Diameter:

152.4 mm (6.00 inch)

Overall Length:

632.97 mm (24.92 inch)

Restriction HR:

254 mm H2O (10.00 inch H2O)

Restriction LR:

152 mm H2O (5.98 inch H2O)

Restriction MR:

203 mm H2O (7.99 inch H2O)

Body Diameter Maximum:

330.2 mm (13.00 inch)
