SKU:

G057512

Availability:

Ready to ship

Weight:

3,750.00 Grams

Width:

17.00 (cm)

Height:

39.00 (cm)

Depth:

22.00 (cm)

Shipping:

Calculated at Checkout

Outlet Diameter:

50.8 mm (2.00 inch)

Brand:

RadialSeal™

Country Of Origin:

United States

HTS Code:

8421310052

NMFC Code:

156600-04

Gross Height:

15.5 IN

Gross Length:

8.8 IN

Gross Volume:

0.5289 FT3

Gross Weight:

2.86 LB

Gross Width:

6.7 IN

Style:

Radialseal

Family:

FPG

Body Length:

214.4 mm (8.44 inch)

Rated Flow HR:

2.6 m³/min (92 cfm)

Rated Flow LR:

1.8 m³/min (64 cfm)

Rated Flow MR:

2.3 m³/min (81 cfm)

Inlet Diameter:

50.8 mm (2.00 inch)

Overall Length:

329.7 mm (12.98 inch)

Restriction HR:

254 mm H2O (10.00 inch H2O)

Restriction LR:

152 mm H2O (5.98 inch H2O)

Restriction MR:

203 mm H2O (7.99 inch H2O)

Body Diameter Maximum:

146 mm (5.75 inch)
