SKU:

G065432

Weight:

5,880.00 Grams

Width:

20.00 (cm)

Height:

44.00 (cm)

Depth:

26.00 (cm)

Shipping:

Calculated at Checkout

Outlet Diameter:

63.5 mm (2.50 inch)

Brand:

RadialSeal™

Country Of Origin:

United States

HTS Code:

8421310052

NMFC Code:

069100-04

Gross Height:

17.5 IN

Gross Length:

10.3 IN

Gross Volume:

0.8136 FT3

Gross Weight:

3.845 LB

Gross Width:

7.8 IN

Style:

Radialseal

Family:

FPG

Body Length:

217.9 mm (8.58 inch)

Rated Flow HR:

4.4 m³/min (155 cfm)

Rated Flow LR:

3.4 m³/min (120 cfm)

Rated Flow MR:

3.8 m³/min (134 cfm)

Inlet Diameter:

63.5 mm (2.50 inch)

Overall Length:

423.8 mm (16.68 inch)

Restriction HR:

254 mm H2O (10.00 inch H2O)

Restriction LR:

152 mm H2O (5.98 inch H2O)

Restriction MR:

203 mm H2O (7.99 inch H2O)

Body Diameter Maximum:

171.2 mm (6.74 inch)
