SKU:

G140261

Weight:

72,480.00 Grams

Width:

54.00 (cm)

Height:

59.00 (cm)

Depth:

91.00 (cm)

Shipping:

Calculated at Checkout

Outlet Diameter:

152.4 mm (6.00 inch)

Width:

483 mm (19.02 inch)

Brand:

Donaclone™

Country Of Origin:

United States

HTS Code:

8421310052

NMFC Code:

069100-04

Gross Height:

23.25 IN

Gross Length:

35.75 IN

Gross Volume:

10.2215 FT3

Gross Weight:

55.8 LB

Gross Width:

21.25 IN

Style:

Tubular

Family:

SBG

Body Length:

353.314 mm (13.91 inch)

Rated Flow HR:

16.6 m³/min (586 cfm)

Rated Flow LR:

12.6 m³/min (445 cfm)

Rated Flow MR:

14.7 m³/min (519 cfm)

Inlet Diameter:

152.4 mm (6.00 inch)

Overall Length:

773.938 mm (30.47 inch)

Restriction HR:

254 mm H2O (10.00 inch H2O)

Restriction LR:

152 mm H2O (5.98 inch H2O)

Restriction MR:

203 mm H2O (7.99 inch H2O)

Body Diameter Maximum:

355.6 mm (14.00 inch)
