SKU:

G160679

Availability:

Ready to ship

Weight:

68,740.00 Grams

Width:

54.00 (cm)

Height:

67.00 (cm)

Depth:

76.00 (cm)

Shipping:

Calculated at Checkout

Outlet Diameter:

177.8 mm (7.00 inch)

Brand:

RadialSeal™

Country Of Origin:

United States

HTS Code:

8421310052

NMFC Code:

069100-04

Gross Height:

26.25 IN

Gross Length:

29.75 IN

Gross Volume:

9.6035 FT3

Gross Weight:

50 LB

Gross Width:

21.25 IN

Style:

Radialseal

Family:

FRG

Body Length:

482.1 mm (18.98 inch)

Rated Flow HR:

22.5 m³/min (795 cfm)

Rated Flow LR:

16.7 m³/min (590 cfm)

Rated Flow MR:

19.8 m³/min (699 cfm)

Inlet Diameter:

177.8 mm (7.00 inch)

Overall Length:

668.8 mm (26.33 inch)

Restriction HR:

254 mm H2O (10.00 inch H2O)

Restriction LR:

152 mm H2O (5.98 inch H2O)

Restriction MR:

203 mm H2O (7.99 inch H2O)

Body Diameter Maximum:

406.4 mm (16.00 inch)
