SKU:

M060158

Weight:

8,120.00 Grams

Width:

28.00 (cm)

Height:

20.00 (cm)

Depth:

58.00 (cm)

Shipping:

Calculated at Checkout

Outlet Diameter:

51.31 mm (2.02 inch)

Country Of Origin:

United States

NMFC Code:

125850-06

Gross Height:

7.7 IN

Gross Length:

22.9 IN

Gross Volume:

1.1225 FT3

Gross Weight:

10.345 LB

Gross Width:

11 IN

Style:

Style 3

Body Length:

465.1 mm (18.31 inch)

Rated Flow HR:

10.8 m³/min (381 cfm)

Rated Flow LR:

6.3 m³/min (222 cfm)

Rated Flow MR:

8.9 m³/min (314 cfm)

Inlet Diameter:

51.31 mm (2.02 inch)

Overall Length:

541.27 mm (21.31 inch)

Body Diameter Maximum:

152 mm (5.98 inch)

Attenuation HR:

20 dBA

Attenuation LR:

15 dBA

Inlet Clock Position:

3:00

Back Pressure Low-Range:

25 mm Hg (0.98 inch Hg)

Back Pressure Mid-Range:

51 mm Hg (2.01 inch Hg)

Back Pressure High-Range:

76 mm Hg (2.99 inch Hg)

Outlet Clock Position:

6:00
