SKU:

M100043

Weight:

20,830.00 Grams

Width:

27.00 (cm)

Height:

27.00 (cm)

Depth:

114.00 (cm)

Shipping:

Calculated at Checkout

Outlet Diameter:

102.11 mm (4.02 inch)

Country Of Origin:

United States

HTS Code:

8708924262

NMFC Code:

125850-09

Gross Height:

10.75 IN

Gross Length:

45 IN

Gross Volume:

2.9395 FT3

Gross Weight:

34.25 LB

Gross Width:

10.5 IN

Style:

Style 2

Body Length:

898.4 mm (35.37 inch)

Rated Flow HR:

48.2 m³/min (1702 cfm)

Rated Flow LR:

27.8 m³/min (982 cfm)

Rated Flow MR:

39.4 m³/min (1391 cfm)

Inlet Diameter:

102.11 mm (4.02 inch)

Overall Length:

1060.45 mm (41.75 inch)

Body Diameter Maximum:

256.44 mm (10.10 inch)

Attenuation HR:

20 dBA

Attenuation LR:

15 dBA

Inlet Clock Position:

6:00

Back Pressure Low-Range:

25 mm Hg (0.98 inch Hg)

Back Pressure Mid-Range:

51 mm Hg (2.01 inch Hg)

Back Pressure High-Range:

76 mm Hg (2.99 inch Hg)

Outlet Clock Position:

12:00
