SKU:

M100572

Weight:

23,430.00 Grams

Width:

39.00 (cm)

Height:

27.00 (cm)

Depth:

89.00 (cm)

Shipping:

Calculated at Checkout

Outlet Diameter:

102.11 mm (4.02 inch)

Country Of Origin:

United States

HTS Code:

8708924169

NMFC Code:

125850-05

Gross Height:

10.5 IN

Gross Length:

35 IN

Gross Volume:

3.2964 FT3

Gross Weight:

24.76 LB

Gross Width:

15.5 IN

Style:

Style 6

Body Length:

711.2 mm (28.00 inch)

Rated Flow HR:

46.9 m³/min (1656 cfm)

Rated Flow LR:

27.1 m³/min (957 cfm)

Rated Flow MR:

38.3 m³/min (1353 cfm)

Inlet Diameter:

102.11 mm (4.02 inch)

Overall Length:

777.7 mm (30.62 inch)

Body Diameter Maximum:

256 mm (10.08 inch)

Attenuation HR:

20 dBA

Attenuation LR:

15 dBA

Inlet Clock Position:

6:00

Back Pressure Low-Range:

25 mm Hg (0.98 inch Hg)

Back Pressure Mid-Range:

51 mm Hg (2.01 inch Hg)

Back Pressure High-Range:

76 mm Hg (2.99 inch Hg)

Outlet Clock Position:

12:00
