SKU:

M101169

Weight:

12,680.00 Grams

Width:

26.00 (cm)

Height:

26.00 (cm)

Depth:

75.00 (cm)

Shipping:

Calculated at Checkout

Outlet Diameter:

102.11 mm (4.02 inch)

Country Of Origin:

United States

HTS Code:

8708924963

NMFC Code:

125850-08

Gross Height:

11 IN

Gross Length:

35.5 IN

Gross Volume:

3.1638 FT3

Gross Weight:

22.41 LB

Gross Width:

14 IN

Style:

Style 3

Body Length:

603.2 mm (23.75 inch)

Rated Flow HR:

56.6 m³/min (1999 cfm)

Rated Flow LR:

31.9 m³/min (1127 cfm)

Rated Flow MR:

44.4 m³/min (1568 cfm)

Inlet Diameter:

102.11 mm (4.02 inch)

Overall Length:

742.2 mm (29.22 inch)

Body Diameter Maximum:

256 mm (10.08 inch)

Attenuation HR:

18 dBA

Attenuation LR:

12 dBA

Inlet Clock Position:

6:00

Back Pressure Low-Range:

25 mm Hg (0.98 inch Hg)

Back Pressure Mid-Range:

51 mm Hg (2.01 inch Hg)

Back Pressure High-Range:

51 mm Hg (2.01 inch Hg)
